WH-160 GSM Door Gate Opener Remote On/Off Relay Switch Remote Control Door Access Wireless Door Opener By Free Call SMS Command

WH-160 GSM Door Gate Opener Remote On/Off Relay Switch Remote Control Door Access Wireless Door Opener By Free Call SMS Command




1.No call charges. The GSM Gate Opener rejects the call from authorized number, then the relay will turn ON/OFF on the first ring.

2.It is no longer traditional to open the door, but it is more interesting to shake the mobile phone to unlock the door.

3.Multiple applications. (gates, bollards, barriers, garage doors, shutters and access doors or  machines).

4.Secure - Using caller ID for identification, unknown callers are ignored.

5.Can be operated from anywhere, no distance limit.

6.Add or remove users by SMS Text command.

7.No need to provide a remote control for different users.

8.Up to 200 authorized phone numbers can be configured.

9.One output with relay (3A/240VAC)for connecting the switch of the door or machines.

10.The relay action will return a SMS confirmation to the owner, this function is editable by user.

11.Two Digital inputs for door sensor, motion sensors or other sensors to protect your door and windows, when any one of them triggered, will send SMS alert message and start the siren  immediately.

12.External AC/DC Power status monitoring, AC/DC On/OFF will send SMS to authorized phone numbers.

13.Inbuilt MCU monitoring the DC input Voltage value, no need additional sensor to save cost.

14.Rechargeable Backup Battery inside can last 8 hours.

15.Based on GSM Network, applied to many applications.


1.Rated Voltage: DC 9V~36V/1A

2.Working temperature: -10℃~+60℃

3.Storage temperature: -20℃~+60℃

4.Relative humidity: 10-90%, No condensation

5.Work frequency:

  GSM: 850/900/1800/1900MHz

  3G WCDMA: 900/2100 MHz UMTS

  3G CDMA2000:850/1900MHz UMTS

  3G: 850/2100MHz UMTS

6.Communication protocol: GSM PHASE 2/2+ (include data service)

7.Related Voltage of the Output Relay: 3A/240V AC

8.SIM Card:Nano type, 3V

9.Antenna: 50 Ω SMA

10.Wired Switch: Supports

11.Wired Zones: 2

12.Backup Battery:3.7V/1000mAH

13.Dimension: 96.5*72*59mm

14.Net Weight: 88g






Packaging Details:

1. Outside package: Standard marine export plywood case.

2. inner package: Stretchy film and plastic film for humidity.

3. We can package according to your requests.

Delivery Detail: Shipped in 5-30 working days after payment.

Production Time:
Normally in stock model products:

Quantity:1-100pcs only 2day ,Quantity:101-2000pcs need 3-15days, >2000pcs please contact with sales to confirm.

OEM time:
5-15days for 1000pcs, if over 10,00pcs, please contact with us to confirm the accurate  production  time.

OEM quantity:
If customized logo on products, MOQ:100 -300pcs;If customized packaging & use manual, MOQ: 500pcs
